SMART TOUCH AMPLIFIER
MC-ZGAY-225T10I
The MC-ZGAY-225T10I is a 2-channel Bluetooth multi-home audio system equipped with USB and TF card support. It powers two to four speakers for homes or small commercial areas and provides simple track, source and volume control.
The system uses a high-efficiency Class-D amplifier and combines Bluetooth, Wi-Fi, RJ45, RS485, Tuya app support and Zigbee gateway functions for smart-home audio and automation integration.
Key Features
- 10-inch crystal panel High-transparency crystal panel with sensitive capacitive touch control.
- RJ45 network interface Wired network interface supports stable installation connectivity.
- RS485 integration RS485 integration enables communication with third-party systems.
- Tuya app control Supports Tuya app for smart-home and audio control.
- Timed playback Supports timed playback for automated room audio schedules.
- Residential deployment Suitable for hotels, villas, homes and children’s rooms.
- Bluetooth connection Adopts Bluetooth wireless connection technology for mobile playback.
- Tuya Zigbee gateway Includes Tuya Zigbee gateway and relay support for smart-home use.
- Phoenix connectors Secure and fast Phoenix connectors for audio input wiring.
- Smart-home functions Controls air conditioning, curtains, light colour, brightness and volume.
- Online audio services Supports Spotify, AirPlay, multi-room and internet radio functions.
- Slim wall design Thin 10-inch touch panel integrates neatly into wall installations.
| System Specifications | |
| Model | MC-ZGAY-225T10I |
| Description | 10-inch Android wall amplifier |
| System | Android 11, RAM 2G / ROM 8G |
| Power RMS | 2 x 25W |
| Speaker Impedance | 4-8 Ohm |
| Display | 10-inch capacitive touch screen, 1280 x 800 IPS |
| Signal-to-Noise Ratio | >= 98dB |
| Frequency Response | 20Hz - 20kHz |
| Power Requirements | 110-250VAC |
| Audio Inputs & Outputs | |
| Music Formats | MP3, WAV, WMA, FLAC, APE, ACC, AC3, OGG |
| Video Formats | MPEG, RM/RMVB, WMV, MOV, MKV, VOB, AVI, 3GP, H.264 |
| Sources | USB, TF card, Bluetooth, Wi-Fi, Spotify, AirPlay and internet radio |
| Control & System Features | |
| Smart Control | Tuya app, Zigbee gateway, relay and RS485 interface |
| Network | Wi-Fi, RJ45 and Bluetooth wireless range up to 10m |
| Environment & Physical | |
| Application | Smart home audio, residential |
| Mounting | In-wall smart touch panel |
| Dimensions | 250 x 172 x 10.5mm |
| Net Weight | 1.2kg |
| Display Size | 10-inch |
